TP-F190
TRAFOPSU
The Common Mode Choke with 2x3.5mH inductance is a high-performance EMI filter designed to provide superior noise suppression across a wide frequency range of 1 kHz to 300 MHz. Ideal for low-current power supplies, DC-DC converters, and LED drivers, this choke is rated for 2.5A continuous current, ensuring reliable performance in a variety of low-to-medium power applications.
With a DC resistance (DCR) of only 10mΩ, this choke ensures minimal power loss and high efficiency, reducing heat generation and improving system reliability. The broadband noise suppression capability makes it an excellent choice for filtering out EMI noise from mains power and switching devices, ensuring cleaner and more stable operation.
Built with a ferrite core, the choke excels in high-frequency filtering and provides effective noise control in industrial, automotive, and consumer electronics applications. Whether you’re designing a new power supply or optimizing an existing system, this low-loss choke ensures your device meets stringent EMI standards while maintaining high efficiency.
Key Features:
Inductance: 2 × 3.5mH
Rated Current: 2.5A
DCR: 10mΩ
SRF: 1 kHz to 300 MHz
Ferrite Core for superior high-frequency performance
The Common Mode Choke with 2x3.5mH inductance is a high-performance EMI filter designed to provide superior noise suppression across a wide frequency range of 1 kHz to 300 MHz. Ideal for low-current power supplies, DC-DC converters, and LED drivers, this choke is rated for 2.5A continuous current, ensuring reliable performance in a variety of low-to-medium power applications.
With a DC resistance (DCR) of only 10mΩ, this choke ensures minimal power loss and high efficiency, reducing heat generation and improving system reliability. The broadband noise suppression capability makes it an excellent choice for filtering out EMI noise from mains power and switching devices, ensuring cleaner and more stable operation.
Built with a ferrite core, the choke excels in high-frequency filtering and provides effective noise control in industrial, automotive, and consumer electronics applications. Whether you’re designing a new power supply or optimizing an existing system, this low-loss choke ensures your device meets stringent EMI standards while maintaining high efficiency.
Key Features:
Inductance: 2 × 3.5mH
Rated Current: 2.5A
DCR: 10mΩ
SRF: 1 kHz to 300 MHz
Ferrite Core for superior high-frequency performance
